30W RF tube co2 fractional laser skin resurfacing scar remove machine

10600-MG04

OVERVIEW:

1.Laser type: RF excitation CO2 laser
2.Wavelength: 10600nm
3.Pulse width:0.1-5.0ms
4.Power :30W

30W RF tube  co2 fractional laser skin resurfacing scar remove machine


Specification:

Wavelength:

10600nm

Laser apparatus:

Sealed off laser device simulated by direct current

Output power:

30w

Spot size:

0.02~0.05mm2

Aiming beam:

Red semiconductor laser (635nm, less than 5mw)

Beam transport device:

Articulated arm with 7-joint and balance weight

Working mode:

Continuous operation

Output Mode:

Continuous, single pulse, interval pulse and super pulse

Scan scope:

Max 20mmx20mm

Scan graphics:

Circle, triangle, square, rectangle,hexagon, ellipse, line

Scanning Mode:

Random , Normal and Midsplit scan

Scanning speed:

More than 10m/s

Energy:

1- 30W

Pulse width

0.1-5.0ms

Distance:

0.1-2.6mm

Input power:

450VA

Cooling system:

Water and air circulation

Environment temperature:

5°C~40°C

Relative humidity:

Less than 80%

Power:

110V / 220V


Principle:

Fractional photo thermolysis creates an array of microscopic thermal wounds, called microscopic treatment zones, at specific depths. Unlike other ablative and nonablative lasers, which produce layers of thermal heating, the FP creates microscopic columns of thermal damage, sparing surrounding tissues and promoting more rapid healing. The FP treatment results which are collagen remodeling and skin turnover are excellent. Removing lentigines and other discolorations and producing fresher, tighter, and more youthful skin could be little to no downtime.



Applications:

1. Reduce lines and deep wrinkles on the face

2. Tighten skin on the face and neck

3. Improve skin tone around eyelids, jowls and neck

4. Rejuvenate sun-damaged skin and improve texture

5. Remove pigmented lesions

6. Improve tone and texture on the chest, arms, and hands

7. Change the appearance of scars.
